Madimack’s enhanced inverter technology, InverMAC, is engineered to support inverter motor operation. The inclusion of product specific proprietary technology allows for precise control of motor speed and energy usage across our range. InverMAC technology supports Madimack’s overall position of unrivalled innovation, sustainability and performance. By incorporating inverter motor technology in creative and unique ways, Madimack is leading the way in the development of energy-efficient products.

TOO EASY Builder's October Promo

Don't be beaten by the October heat!
Madimack is making it TOO EASY to keep the team cool with a
FREE Cooler Bag + 6 Powerades, all October.

No purchase required!

See T&C for details.

logo-inverECO-LITE-positive
  • icon-fan

    Front Air Flow Fan

    Engineered for improved efficiency and flexible installation.

  • icon-heat-exchanger

    Superior Durability

    Titanium Heat Exchanger with 25-Year Warranty.

  • icon-wifi

    Wi-Fi Convenience

    Control your system anytime, anywhere with seamless connectivity.

  • icon-design

    Sleek Design

    Modern aesthetics to complement your pool build.

  • icon-crc

    Corrosion-Resistant Casing

    Built to withstand harsh outdoor conditions for lasting durability.

  • icon-operation

    Efficient Operation

    Optimised performance for maximum energy savings with a COP of up to 11.0.

  • icon-pv-ready

    PV-Ready with Quick-Connect

    Direct PV hook-up with no rewiring for faster installs and smarter energy use.

  • icon-heating-and-cooling

    Heat & Cool

    One unit, heating and cooling for year-round comfort.

  • icon-plug

    Plug & Play

    For additional savings (time & money)

Become Our Partner
Model Eco Lite 9kW Eco Lite 11kW Eco Lite 14kW Eco Lite 18kW Eco Lite 24kw
PERFORMANCE CONDITION: Air 27°C/ Water 27°C/ Humid. 80%
Heating capacity (kW) 9.5 11 14 18 24.2
COP Range 10.6~5.7 10.8~5.8 11~6 10.8~5.7 10.8~6.3
PERFORMANCE CONDITION: Air 15°C/ Water 26°C/ Humid. 70%
Heating capacity (kW) 6.6 7.8 9.8 12.4 16
COP Range 6.2~4.1 6.2~4.2 6.6~4.3 6.4~4.2 6.6~4.5
PERFORMANCE CONDITION: Air 35°C/ Water 28°C/ Humid. 80%
Cooling capacity (kW) 3.4 4.3 5.4 6.6 8.8
TECHNICAL SPECIFICATIONS
Temperature set point range (℃) 8ºC - 40ºC
Operating air temperature (°C) 0°C~43°C
Heat exchanger Twisted Titanium Heat Exchanger
Casing ABS Casing
Power supply 230V/ 1Ph/ 50/60 Hz
Electrical connection 10A Plug (3 x 1.5 mm2) Hardwired (3 x 4.0 mm2)
Power cord (mm2) 3 x 1.5 3 x 4.0
Rated input power (kW) 0.45~1.60 0.52~1.86 0.64~2.28 0.83~2.96 0.72~3.81
Rated input current (A) 1.96~6.96 2.26~8.09 2.78~9.91 3.61~12.87 3.13~16.56
Maximum input current (A) 10 10 10 15 20.5
Breaker Rated Current (A) 15 15 15 20 25
Sound level at 50% 1m dB(A) 47.0 48.5 48.7 49.2 51.1
Sound level at 1m dB(A) 41.8~53.8 42.9~53.5 44.2~55.0 46.3~58.2 46.9~58.7
Sound level at 10m dB(A) 21.8~33.8 22.9~33.5 24.2~35.0 26.3~38.2 26.9~38.7
Advised water flow (L/min) 40~70 50~80 70~100 100~140 160~200
Water connection (mm) 40
Refrigerant Gas R-32
Net dimension LxWxH (mm) 903 * 347 * 654 903 * 347 * 654 903 * 347 * 654 991 * 347 * 654 991 * 420 * 757
Packaging Dimension LxWxH (mm) 950 * 375 * 685 950 * 375 * 685 950 * 375 * 685 1040 * 365 * 685 1040 * 435 * 800
Gross Weight (kg) 52 53 55 67 78
Net weight (kg) 46 47 49 60 68
