New age pool heating & cooling World first three directional airflow Easier installation requirements COP22 world leading efficiency Quietest heat pump in the world Commercial grade centrifugal fan 7 Years All Parts Warranty V4 coming soon

View InverELITE V4
hero-banner-2

Finely engineered design enhancements providing significant advancements in performance and resulting in a world best COP of 22.

COP is the industry standard for measuring the efficiency of heat pumps. It represents the relationship between the heat generated and the power used to generate it. Essenstially, the higher the COP the more efficient the unit.

Triple layered sound insulation, commercial grade centrifugal fan, a revolutionary 3-Directional airflow, premium twin rotary compressor and three internal reflectors have joined forces to make Madimack’s InverELITE V4 the world’s most efficient, quietest, best performing pool heat pump.

product
video poster image
banner-3d-airflow

3D Airflow

The V4 provides the world's first 3 directional ventilation.

In a revolutionary step for pool heating and cooling solutions, Madimack engineers crafted ventilation design that reduces ventilation requirements, simplifies installation requirements and enhances operation efficiencies significantly.

banner-compressor

Twin Rotary Compressor

The V4 has the fastest heat-up times of any pool heat pump.

High-grade componentry such as a twin rotary compressor and commercial grade centrifugal fan contribute to the outstanding Power to Performance ratio delivered by the V4.

eDM1 BodyBanners_InverELITE V4_4

Commercial Grade Centrifugal

Design enhancements such as the inclusion of a commercial grade centrifugal fan underpins the outstanding delivery of efficiency, sound & performance.

Triple layered sound insulation

The V4 is the quietest heat pump in the world. Its finely engineered design includes 3 layers of insulation (condensed fibre, foam and metal jacket),resulting delivering an almost silent experience.

  • icon-warranties

    Premium Materials

    The V4 is protected by an anti-corrosive, marine grade, aluminium alloy metal jacket to ensure it withstands nature’s elements in all climates.

  • icon-check

    Quick Connect

    External plugs for easy access and less intrusive access to the heat pump to simplify installation and provide additional control. It is the only heat pump available with external universal controls. It is universal because multiple devices can be used and connect into them. The connectors come pre-fitted to the heater and require manual wiring.

  • ico-cop22

    COP22

    COP is the industry standard of efficiency in heat pump technology (coefficient of performance). Madimack’s V4 offers an unrivalled COP of 22

  • icon-warranties

    Market Leading Warranties

    7 year All Parts
    10 year Compressor
    25 year Heat Exchanger

  • icon-heat-exchanger

    Heat Exchanger

    Extracts heat from the air efficiently.

  • icon-panel-control

    Display Screen

    Madimack’s V4 display screen contains additional features and allows for simplifies user controller & operation.



Find Out More: InverELITE V4

Fill out our contact form and a member of our customer support team will be in touch:
VIEW BROCHURE
Model ESV3-110 ESV3-140 ESV3-170 ESV3-220 ESV3-270 ESV3-320 ESV3-400
PERFORMANCE CONDITION: Air 27°C/ Water 27°C/ Humid. 80%
Heating capacity (kW) 11.5 14 17 22.5 26.9 31.8 40.5
COP range 16.0~7.3 16.0~7.4 16.1~7.1 16.2~7.1 16.1~7.3 16.4~7.2 16.0~7.0
PERFORMANCE CONDITION:Air 15°C/ Water 26°C/ Humid. 70%
Heating capacity (kW) 7.7 9.3 11.5 15.0 18.0 21.8 29.0
COP range 7.5~5.0 7.6~5.1 7.8~5.0 8.2~5.1 7.9~5.1 8.0~5.2 8.3~5.1
PERFORMANCE CONDITION:Air 35°C/ Water 26°C/ Humid. 70%
Cooling Capacity (kW) 4.6 5.6 6.5 8.1 10.2 12.2 15.0
TECHNICAL SPECIFICATIONS
Operating air temperature(°C) -15 ~ 43
Compressor Twin-Rotary Mitsubishi DC Compressor
Heat exchanger Twisted Titanium Heat Exchanger
Casing Marine Grade Aluminium Alloy
Power supply 230V/1Ph 400V 3Ph
Electrical connection 10A Plug 15A Plug Hardwired Hardwired Hardwired Hardwired Hardwired
Rated input power (kW) 0.24~1.79 0.29~2.16 0.36~2.67 0.45~3.33 0.54~4.0 0.59~4.36 0.78~5.8
Rated input current (A) 1.04~7.78 1.09~8.34 1.57~11.63 1.96~14.48 2.35~17.39 2.56~18.96 1.13~8.41
Maximum input current (A) 9 11 13 16 18 21 10.5
Sound level at 1m dB(A) 36.3~44.5 36.5~45.9 39.3~46.7 39.5~49.8 39.8~50.2 40.3~50.8 40.6~51.3
Sound level at 10m dB(A) 16.3~24.5 16.5~25.9 19.3~26.7 19.5~29.8 19.8~30.2 20.3~30.8 20.6~31.3
Advised water flow (L/Min) ±20 65 80 100 125 150 180 230
Water connection (mm) 40
Net Weight (kg) 66 73 75 91 114 136 160
Net dimension LxWxH (mm) 750x504x656 750x504x656 839x504x656 979x504x756 1132x514x756 1029x512x1107 1139x512x1106
RRP Madimack pool heat pump price list

*ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE PLEASE SEE DATA PLATE ON PRODUCT FOR SPECIFIC SPECIFICATIONS.

*Unless purchased through a Certified Madimack Online Dealer, product warranties revert to statutory 12 month warranty. Refer to Madimack website for list of Certified Online Dealers in order to secure expert service & support of Madimack products.
