Efficiency to keep you swimming in your pool longer with perfect water temperature

Stepless DC Inverter allows full control over the speed of the compressor and fan motor. InverTITAN will adjust precisely and intelligently to the heat demand of your swimming pool to maintain stable temperature throughout the season.

Double Energy Saving

InverTITAN runs at full speed at the beginning of the season to heat your pool faster. Once close to reaching set temperature, it will adjust to low-speed operation and maintain stable temperature throughout the season. InverTITAN will achieve double energy saving compared to single speed On/Off heat pumps.

COP Up To 14.6

Based on the principle of low-speed performance, InverTITAN can achieve COP of up to 14.6 when operating at 20% capacity.

video poster image

Ultra quiet solution

Thanks to InverMAC Technology, the sound level of InverTITAN is 34.4dB(A) at 10ft. It can be more than 15 times quieter than generic on/off heat pumps.

InverTITAN-noise-compare-chart-text-outline

45x quieter

  • icon-soft-start

    Soft Start

    InverTITAN will start from 0 amps and increase steadily protecting electrical systems.

  • icon-temperature

    Operation down to 32°F

    Built to operate in the the coldest weather and extend your pool season into the winter.

  • icon-wifi

    Built-in Wifi

    Built-in Wi-Fi and smart app provides convenience to control your pump on-the-go.

  • icon-defrosting

    Smart & Quick Defrosting

    InverTITAN is equipped with reverse cycle defrosting. It will detect frost accumulation during operation and automatically switch to defrosting mode.

Advanced features & benefits

  • icon-compressor

    Twin-rotary Compressor

    Significantly reduced operating noise.

  • icon-eev

    Electronic Expansion Valve

    Optimized flow of refrigerant 20% higher COP.

  • icon-heat-exchanger

    Twisted Titanium Heat Exchanger

    Increased area for heat exchange 40% higher efficiency.

Get in touch

Complete the contact form and a Madimack team member will be in touch. Don't forget to review the full suite of products and services on our website www.madimack.com/us
Model ITV090 ITV112 ITV140
PERFORMANCE CONDITION: Air 80°F/ Water 80°F/ Humidity 80%
Heating capacity (BTU) 90,000 112,000 140,000
Heating capacity (KW) 26 33 41
COP Range 14.3 ~ 6.0 14.5 ~ 6.1 14.6 ~ 6.0
PERFORMANCE CONDITION: Air 80°F/ Water 80°F/ Humidity 63%
Heating capacity (BTU) 84,000 105,000 131,000
Heating capacity (KW) 25 31 38
COP Range 12.7 ~ 5.7 12.8 ~ 5.8 13.3 ~ 5.7
PERFORMANCE CONDITION: Air 50°F/ Water 80°F/ Humidity 63%
Heating capacity (BTU) 54,000 67,200 85,000
Heating capacity (KW) 16 20 25
COP Range 5.1 ~ 4.2 5.1 ~ 4.1 5.2 ~ 4.2
TECHNICAL SPECIFICATIONS
Operating air temperature (°F) 14 ~ 109
Operating air temperature (°C) -10 ~ 42
Power supply 230V/1 Ph/60Hz
Water connection (mm)/(inch) 60.3mm/2"
Rated input power at air 80°F (kW) 0.57 ~ 4.40 0.70 ~ 5.38 0.89 ~ 6.84
Rated input power at air 80°F (BTU) 2000 - 15000 2400 - 18000 3000 - 23000
Rated input current at air 80°F (A) 2.49 ~ 19.13 3.04 ~ 23.39 3.87 ~ 29.74
Maximum input current (A) 28 32.5 40.0
Sound level at 10ft dB(A) LP 34.3 ~ 46.5 35.2 ~ 48.3 38.8 ~ 51.1
Advised water flux (L/min) 125 ~ 155 135 ~ 165 135 ~ 225
(GPM) 33.0 ~ 41.0 35.7 ~ 43.6 35.7 ~ 69.4
Net dimension LxWxH (mm) 935 × 696 × 988 935 × 696 × 988 1034 × 820 × 1054
(inch) 36.8" × 27.4" × 38.9" 36.8" × 27.4" × 38.9" 40.7" × 32.3" × 41.5"
Net Weight (kg) 130 135 158
(lb) 288 297.0 347.6

*ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE PLEASE SEE DATA PLATE ON PRODUCT FOR SPECIFIC SPECIFICATIONS.

*Unless purchased through a Certified Madimack Online Dealer, product warranties revert to statutory 12 month warranty. Refer to Madimack website for list of Certified Online Dealers in order to secure expert service & support of Madimack products.
