EFFICIENT PERFORMANCE AND SIMPLE OPERATION

Become a Dealer
InverEco-US-rating-new

InverECO is powered by InverMAC Technology, Madimack’s enhanced inverter technology, enabling optimised control of the pump’s motor. The result is dramatic reduction in energy consumption and reduction in operating noise. For backwashing purposes, the InverECO can operate at 100% speed, in contrast, when used during daily filtration, which requires a reduced flow rate, the eco inverter heat pump aligns and drops its operating rate.

Double Energy Saving

InverEco runs at full speed at the beginning of the season to heat your pool faster. Once close to reaching set temperature, it will adjust to low speed operation and maintain stable temperature throughout the season. lnverEco will achieve double energy saving compared to single-speed On/Off heat pumps.

COP UP TO 10.6

Based on the principle of low speed performance, lnverEco can achieve a COP of up to 10.6 when operating a 20% capacity.

video poster image

Ultra quiet solution

InverECO-noise-compare-chart-new

Quiet achiever

  • Boost & Silence

    Boost & Silence

    Switch between Boost mode to heat your pool faster, and Silence mode when quieter operation is preferred.

  • heat-and-cool

    Heat & Cool

    With integrated heating and cooling into a single unit, enjoy your swimming pool any season of the year.

  • soft-start

    Soft Start

    lnverEco will start from 0 amps and increase steadily to protect your electrical system.

Other features

  • control-system

    Dedicated pool heating inverter control system

  • wifi

    Optional Wi-Fi module and smart app

  • eev

    Electronic expansion valve technology

  • heat-exchanger

    Twisted titanium heat exchanger

  • compressor

    Twin-rotary Inverter compressor

  • temperature

    Down to 32°F operation temperature

Get in touch

Complete the contact form and a Madimack team member will be in touch. Don't forget to review the full suite of products and services on our website www.madimack.com/us
View Brochure
Model IEA320 IEA400 IEA500 IEA660
PERFORMANCE CONDITION: Air 80°F/ Water 80°F/ Humidity 80%
Heating capacity (BTU) 32,000 40,000 50,000 66,000
Heating capacity (KW) 9 12 15 19
COP Range 10 0 ~ 6.7 10.7 ~ 6.0 10.2 ~ 6.2 11.6 ~ 6.2
PERFORMANCE CONDITION: Air 80°F/ Water 80°F/ Humidity 63%
Heating capacity (BTU) 31,000 37,500 48,000 61,000
Heating capacity (KW) 9 11 14 18
COP Range 8.7 ~ 6.3 9.9 ~ 5.6 9.2 ~ 6.0 11.1 ~ 5.8
PERFORMANCE CONDITION: Air 50°F/ Water 80°F/ Humidity 63%
Heating capacity (BTU) 17,500 21,400 24,000 28,000
Heating capacity (KW) 5 6 7 8
COP Range 4.5 ~ 4.1 5.0 ~ 4.0 5.5 ~ 4.6 6.2 ~ 5.0
TECHNICAL SPECIFICATIONS
Advised pool volume (gallons) * ≤8,000 ≤11,000 ≤14,000 ≤18,000
Operating air temperature (°F) 32 ~ 109
Operating air temperature (°C) 0 ~ 42
Heat exchanger Titanium in PVC
Power supply 230V/1 Ph/60Hz
Water connection (mm)/(inch) 48.3mm/1.5"
Rated input power at air 80°F (kW) 0.27 ~ 1.42 0.37 ~ 1.87 0.43 ~ 2.41 0.54 ~ 3.37
Rated input power at air 80°F (BTU) 900 - 4800 1300 - 6400 1500 - 8200 1900 - 11500
Rated input current at air 80°F (A) 1.17~6.17 1.61~8.13 1.87~10.43 2.35~14.65
Maximum input current (A) 9.0 10.8 12.8 16.8
Sound level at 10ft dB(A) LP 33.2 ~ 45.0 33.8 ~ 45.2 34.7 ~ 45.8 38.4 ~ 47.1
Advised water flux (L/min) 50 ~ 67 67 ~ 100 83 ~ 116 108 ~ 142
(GPM) 13.2 ~ 17.7 17.7 ~ 26.4 21.9 ~ 30.6 28.5 ~ 37.5
Net dimension LxWxH (mm) 961 × 315 × 658 961 × 315 × 658 961 × 315 × 658 961 × 395 × 660
(inch) 37.8" × 12.4" × 25.9" 37.8" × 12.4" × 25.9" 37.8" × 12.4" × 25.9" 37.8" × 15.6" × 25.9"
Net Weight (kg) 47 46 52 61
(lb) 103.6 101.4 114.7 134.5

*ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE PLEASE SEE DATA PLATE ON PRODUCT FOR SPECIFIC SPECIFICATIONS.

*Unless purchased through a Certified Madimack Online Dealer, product warranties revert to statutory 12 month warranty. Refer to Madimack website for list of Certified Online Dealers in order to secure expert service & support of Madimack products.
