Ultimate pool heating & cooling solution. Efficiency and performance guaranteed.

Become a Dealer
hero-inverElite-v2-w-badges-na

InverMAC Technology

Madimack’s enhanced inverter technology, InverMAC, is engineered to support inverter motor operation. The inclusion of product specific proprietary technology allows for precise control of motor speed and energy usage across our range. InverMAC technology supports Madimack’s overall position of unrivalled innovation, sustainability and performance. By incorporating inverter motor technology in creative and unique ways, Madimack is leading the way in the development of energy-efficient products.

  • icon-backward-airflow

    Backward Airflow System

    It draws air from both sides and blows out from the back side evenly. With innovative backward airflow design.

  • icon-crc

    Premium Weatherproof Casing

    The elegant casing gives a sleek, premium feel resistant to weather, UV and corrosion.

video poster image

Extreme silence

Thanks to Madimack’s Sound Shield Technology, the sound level of InverELITE V2 can be as low as 45.5 dB(A) at 10 ft distance. Whisper quiet!

InverElite-noise-compare-chart-new

Powered by inverMAC technology

Stepless DC Inverter allows full control over the speed of both the compressor and fan motor. The smart control system will adjust the heating capacity automatically to satisfy the actual demand of the pool.

illustration-energy-saving-lrg

Double Energy Saving

At the beginning of the pool season, InverELITE V2 will run at full speed to heat up the pool rapidly. Once pool temperature is getting close to set point, InverELITE V2 automatically adjusts to lower speed, offering more efficient and quiet operation.

illustration-cop-lrg

Cop Up To 15.2

With COP of 15 at low speed to maintain pool temperature, InverELITE V2 can get 150,000 BTUs of heat output for every 10,000 BTUs consumed.

illustration-mode-lrg

Heating & Cooling

InverELITE V2 can heat up your pool or cool it down to the set temperature. Don’t let the weather stop you from enjoying your swimming pool.

  • icon-soft-start

    Soft Start

    InverELITE V2 will start from 0 amps and increase steadily protecting electrical systems.

  • icon-temperature

    Operation down to 5°F (-15°C)

    Built to operate in cold weather and extend your pool season.

  • icon-wifi

    Built-in Wi-Fi

    Built-in Wi-Fi and a smart app provide convenience to control your heat pump on-the-go.

  • icon-defrosting

    Smart & Quick Defrosting

    InverELITE V2 is equipped with reverse cycle defrosting. It will detect frost accumulation during operation and automatically switch to defrosting mode.

Advanced Features & Benefits

  • icon-compressor

    Twin-rotary Compressor

    Significantly reduced operating noise

  • icon-eev

    Electronic Expansion Valve

    Optimized flow of refrigerant 20% higher COP

  • icon-heat-exchanger

    Twisted Titanium Heat Exchanger

    Increased area for heat exchange 40% higher efficiency

Get in touch

Complete the contact form and a Madimack team member will be in touch. Don't forget to review the full suite of products and services on our website www.madimack.com/ca
Model InverElite 84,000 InverElite 116,000
Model Name ISAC840 ISAC1100
SKU INVELITE084 INVELITE1100
PERFORMANCE CONDITION: AIR 80°F / WATER 80°F / HUMIDITY 80%
Heating capacity (BTU) 76,000 105,000
COP Range 5.6 5.6
PERFORMANCE CONDITION: AIR 80°F / WATER 80°F / HUMIDITY 63%
Heating capacity (BTU) 71,000 101,000
COP Range 5.3 5.4
PERFORMANCE CONDITION: AIR 50°F / WATER 80°F / HUMIDITY 63%
Heating capacity (BTU) 30,196 47,188
COP Range 4.7 4.7
TECHNICAL SPECIFICATIONS
Temperature set point range (°F/°C) 64~104/ 18~40
Operating air temperature (°F/°C) 5~109/ -15~43
Heat exchanger Titanium in PVC
Power supply 208V ~ 230V/1 Ph/ 50/60Hz
Electrical Connection Hardwired
(3 x 10 AWG/ 3 x 6.0 mm2)		 Hardwired
(3 x 8.0 AWG/ 3 x 10 mm2)
Minimum Circuit Ampacity (MCA) 25 40
Max. Rating Overcurrent Protection (MOP) 35 60
Rated input power (kW) at air 80°F 0.64~3.98 0.66~4.74
Rated input current (A) at air 80°F 2.86~17.33 2.87~20.6
Maximum input current (A) 23 30
Sound level at 10ft dB(A) 30.8 ~ 44.5 32.0 ~ 45.4
Sound level at 3ft dB(A) 40.3 ~ 54.0 41.5 ~ 54.9
Advised water flux/ flow ± 20% (GPM/ LPM) 21.9 ~ 30.6/ 83 ~ 116 35.1 ~ 44.1/ 133 ~ 167
Water Pressure Drop (kPA) 5.6 10.6
Water connection (inch/mm) 2/50
Refrigerant Gas R410A
Maximum air volume (m3/h) 6100 7050
Net dimension LxWxH (in/ mm) 41.7” × 16.9” × 37.7”/
1060 × 430 × 957		 51.7” × 19.3” × 37.7”/
1314 × 489 × 957
Net weight (lb/kg) 211.6/ 96 275.6/ 125
Gross weight (lb/kg) 273.4/ 124 341.7/ 155
Packaging dimension LxWxH (in/ mm) 44.1” × 18.4” × 38.8”/
1121 × 467 × 985		 53.9” × 21.5” × 39.0”/
1370 × 547 × 990

*The data above is only for reference. For specific data, please refer to the nameplate on the unit.
